Nomenclature CDE 350
Spare parts CDE 350
Rep Code Qty Pièce Spare part
1 B02016+PERCAGE 2 Disque émaillé diam 350 Enamelled cast iron plate 350
2 D02013 2 Résistance blindée Armoured heating element
3 67042 2 Serre résistance diam 350 Heating element holder 350
4 66019 2 Contre disque Gridle holder
5 A16014 1 Bornier 6 plots Six holes domino
6 68044 1 Plateau disque Griddle plate
7 68039 1 Ceinture Casing
8 A13017 4 Pied Foot
9 F05017 1 Râteau en bois Wooden scraper
10 68040 1 Fond socle Bottom casing
11 A08009 2 Voyant vert Green pilot light
12 C01010 1 Cable Cord
13 A10032 1 Presse étoupe 16 Cord closer 16
14 68034 1 Renfort disque Plate holder
15 68041 1 Bandeau Control panel
16 A08003 2 Voyant orange Orange pilot light
17 A06042 2 Thermostat Thermostat
18 A14113 2 Bouton 9 H Knob 9 H
19 A01020 2 Commutateur Commutator
5. FUNCTIONING / MANIPULATION
a) Installation / assembly:
- Unpack carefully the device of its packaging.
- Place it on a plane and heatproof surface.
- Never place the device near a wall or near a partition makes of combustible materials
even if it is very well isolated.
- A distance of minimum 10 cm with the partition or the wall is necessary.
b) First starting:
Before the first use, remove the anti-corrosion protection fat with a cleaner and a wet
sponge.
During the first use, grease your plate with oil and preheat the crepe machine during
about 15 min. Once preheating is finished, set the thermostat on the wished tempera-
ture.
First cleaning
Clean the device before the first use. (See 6. Cleaning)
Connection of the device
- Check that the tension and the frequency of the electricity network suit to the values
indicated on the descriptive plate.
- Make sure that every control knob is positioned on 0.
- Check that neither the cord nor the plug are damaged
- Unwind completely the electric power cable and connect it in a plug connected with
the earth.
- The device is connected.
NB: in case of connection of the device in a plug without earth protection or directly on
the electricity network, confide its connection to a qualified person .
c) Use of device :
Elements of command and display
Command/Display Function
Thermostat (n°2 on picture) On/off + Temperature setting
Orange pilot light
(n°4 on picture)
Machine is heating (pilot light on)
Temperature reached (pilot light off)
Green pilot light (n°1 on pic-
ture)
Machine is on (pilot on)
Machine is off (pilot off)
5
