Nomenclature CSE 400
Spare parts CSE 400
Rep Code Qty Pièce Spare part
1 B02049 1 Disque émaillé diam 400 Enamelled cast iron plate 400
2 D02163 1 Résistance blindée Armoured heating element
3 67049 1 Serre résistance diam 400 Heating element holder 400
4 67048 1 Tôle protection Protecting S/steel
5 A16013 1 Bornier 3 plots Three holes domino
6 68030 1 Plateau disque Griddle plate
7 68031 1 Ceinture Casing
8 A13017 4 Pied Foot
9 F05017 1 Râteau en bois Wooden scraper
10 68032 1 Fond socle Bottom casing
11 A08009 1 Voyant vert Green pilot light
12 C03007 1 Cordon avec prise Cord with plug
13 A10032 1 Presse étoupe 16 Cord closer 16
14 68034 2 Renfort disque Plate holder
15 68033 1 Bandeau Control panel
16 A08003 1 Voyant orange Orange pilot light
17 A06042 1 Thermostat Thermostat
18 A14113 1 Bouton 9 H Knob 9 H
19 A01020 1 Commutateur Commutator
- For cleaning, only use non-abrasive products, clean regularly the external walls of
your device with warm water and wash liquid: avoid the abrasive towelling. Rinse your
device with a wet sponge. Dry it with a soft cloth
- Never clean the device under a water jet, the infiltrations would risk to damage it in a
irreparable way.
- Never immerse the device, the cord or the plug in the water or quite other liquid to
avoid any electric shock.
- During a prolonged non-use, we recommend you strongly to keep the device
shielded from the humidity and to grease the plate.
7. TECHNICAL SPECIFICATIONS
Wires colours correspondence Phase 1 Brown
Phase 2 Black
Phase 3 Grey
Neutral Blue
Earth Yellow-Green
The equipotential connection marked by this symbol must be linked with the
equipotential conductive connection of your installation by means of a minimum con-
duction of a 2.5 mm² section.
8. NORMS AND LEGALS DISPOSALS
The device is conform to :
IEC/EN 60335-1
IEC/EN 60335-2-38
EN 55014-1 + 55014-2
EN 61000-3-2 + 61000-3-3
Models CSE 350
Outside dimen-
sions mm
450x500x240
Weight
14.5 Kg
Power
3000 W
Voltage
220-240 V N~
No element
1
Current
13 A
CSE 400
450x500x240
18 Kg
3600 W
1
15.7 A
220-240 V N~
CDE 350
860x500x240
29 Kg
6000 W
2
13 A/Phase
380-415 V 3
N~
CDE 400
860x500x240
34 Kg
7200 W
2
15.7 A/Phase
380-415 V 3 N~
