Nomenclature CSE 350
Spare parts CSE 350
Rep Code Qty Pièce Spare part
1 B02016+PERCAGE 1 Disque émaillé diam 350 Enamelled cast iron plate 350
2 D02013 1 Résistance blindée Armoured heating element
3 67042 1 Serre résistance diam 350 Heating element holder 350
4 66019 1 Contre disque Griddle holder
5 A16013 1 Bornier 3 plots Three holes domino
6 68043 1 Plateau disque Griddle plate
7 68031 1 Ceinture Casing
8 A13017 4 Pied Foot
9 F05017 1 Râteau en bois Wooden scraper
10 68032 1 Fond socle Bottom casing
11 A08009 1 Voyant vert Green pilot light
12 C03007 1 Cordon avec prise Cord with plug
13 A10032 1 Presse étoupe 16 Cord closer 16
14 68033 1 Bandeau Control panel
15 A08003 1 Voyant orange Orange pilot light
16 A06042 1 Thermostat Thermostat
17 A14113 1 Bouton 9 H Knob 9 H
18 A01020 1 Commutateur Commutator
The guarantee comes to an end in case of intervention, of repair, of modification by
no qualified persons, or of use in inappropriate purposes.
