Roller Grill Savoye - Technical Specifications

14
Nomenclature PANINI
Spare parts PANINI
Rep Code Q
t
Pièce Spart part
1 A15008 1 Poignée de plaque
supérieure
Top plate handle
2 D02171 1 Résistance haute Top heating element
3 37022 1 Guide plaque supé-
rieure
Top plate guide
4 37281 1 Cache ressort Spring protection
5 D02170 1 Résistance basse Bottom heating element
6 A16013 1 Bornier 3 trous Three holes domino
7 A16012 1 Bornier 2 trous Two holes domino
8 A06032 1 Thermostat Thermostat
9 37261 1 Bac à sauce Sauce lid
10 A07025 1 Interrupteur Switch
11 A14078 1 Bouton Knob
12 A08003 1 Voyant orange Orange pilot light
13 A08009 1 Voyant vert Green pilot light
14 A13003 4 Pied Foot
15 A10032 1 Presse étoupe 16 Cord closer 16
16 C03007 1 Cordon avec prise Cord with plug
17 C04008 1 Gaine Ressort Spring girdle
18 B04027 2 Bride poignée Handle strap
19 C04007 1 Isolant Insulation
20 F01042/43 1 Poignée complète Handle assembly
21 37064 1 Capot inox Stainless steel cover
22 B02023+PTR 1 Plaque inférieure
rainurée
Bottom grooved
cast iron plate
B02025+PTR 1 Plaque inférieure
lisse
Bottom flat
cast iron plate
23 B02024+PTR 1 Plaque supérieure
rainurée
Top grooved
cast iron plate
B02033+PTR 1 Plaque supérieure
lisse
Top flat cast iron plate
24 37061 1 Cadre Frame
25 37106 1 Serre résistance bas Bottom element plate
26 C05016 1 Fil de terre Earth wire
27 A10029 3 Attache cable Wire ties
28 37105 1 Serre résistance haut Upper element plate
B07019 1 Ressort Spring
37090 1 Racloir Scraper
7. TECHNICAL SPECIFICATIONS
Wires colours correspondence Phase 1 Brown
Phase 2 Black
Phase 3 Grey
Neutral Blue
Earth Yellow-Green
The equipotential connection marked by this symbol must be linked with the
equipotential conductive connection of your installation by means of a minimum con-
duction of a 2.5 mm² section.
8. NORMS AND LEGALS DISPOSALS
The device is conform to :
IEC/EN 60335-1
IEC/EN 60335-2-38
EN 55014-1 +55014-2
EN 61000-3-2 + 61000-3-3
Humidity protection degrees IPX4, directive from 12/01/2008
9. ELIMINATION OF THE ELECTRIC AND ELECTRONIC WASTE
The device respects the directives:
2002 / 96 / CE ( DEEE) N°34270064800021
2002 / 95 / CE ( ROHS)
2006/95 CE
2004/108 CE
Models
Savoye Panini Majestic Panini Double
Outside dimensions
mm
330x385x220 430x385x220 600x385x220 835x385x220
Cooking surface
mm
260x240 360x240 535x240 2 x (360x240)
Weight
18 Kg 22.5 Kg 33.5 Kg 45 Kg
Power
2000 W 3000 W 4000 W 6000 W
No element
2 2 4 4
Current
8.7 A 13 A 8.7 A / Phase 13 A / Phase
Voltage
220-240 V ~ 220-240 V ~ 380-415 V
3 N ~
380-415 V
3 N ~
7
