Rollplay W441 - Left Rear Wheel Assembly; Left Rear Wheel Installation

10
Assemble the Left Rear Wheel
Left Rear Wheel:
1.
2.
Slide the large washer onto the rear axle.
Slide the inner wheel spacer onto the axle.
3. Slide the left rear wheel onto the left rear axle. The side with the
gear teeth faces inward.
4. Slide the large washer onto the rear axle.
5. Insert the straight side of the snap pin through the hole at the end of
the axle to keep the wheel in place.
6. Finally snap the wheel cover onto the wheel to complete the
assembly.
Rear wheel
Large washer
Inner wheel spacer
Large washer
Snap pin
Wheel cover
