22 4 77
3 of 6 SY/Ml02 Issue 3
5
Replace the battery box cover, tool tray and trim panel.
CHLORIDE BATTERY - TO FIT (AS A REPLACE~1ENT FOR THE PREVIOUS TYPES
OF BATTERY)
A Motor cars with battery clamping plate UD 18712 {see Fig. 2)
l Remcve
the trim ~anel, tool tray, battery box cover
and luggage compartment floor covering.
2 Disconnect the battery connections and remove the battery
clamping plate and battery.
3 Secure the t~·rc locally rnanuf actured wooden s~ac::.ng blocks
(see Fig. l inset B) to the sides of the battery box as
shown in Figure 1 inset A, with a suitable impact adhesive.
4 Fit the new Chloride battery. Connect the battery
connections and fit the battery box cover, tool tray,
trim panel and floor covering.
B ~fotor cars ·..;ith either battery clamping olate UD 10534 or
uD 15921 {see Fig. 3}.
1 Remove the tri~ ~anel, tool tray, battery box cover
and luggage compartreent floor covering.
2 Disconnect the battery connections anc remove the
battery clarnping ?late and battery.
3 Secure the two locally manufactured wooden spacing
blocks (see Fig. 1 inset B) to the sides of the battery
box as shown in Ficure l inset A, with a suitable iMcact
adhesive. "' -
4 Referring to ;igure 3, mark out the areas of metal to
be rereoved from the clamping plate. (Without this metal
remc•:ed, the clar::r,>ing pla4=e would not fit the new
Chloride battery).
S Using a hacksaw, remove the appropriate areas; smooth
all sharp edges.
6 Paint all bare metal edges·using a suitable proprietary
black paint.
7 Fit the new Chloride battery, and secure with the
ncdified cla~ping plate. Connect the battery connections
and fit the battery ~ox cover, tool tray, trim panel and
floor covering.
C Time allowed:
1 ~anufacturing and fitting wooden spacing blocks - 0.25 hours.
