Roma GECCO - Wiring and Control Board; Signal Lamp Wiring Diagram; Control Board and DIP Switches

23
[DE] siehe Seite 27
[EN] view page 29
[FR] cf. page 31
[NL] zie bladzijde 33
5
4
3
2
1
Klemme / Borne / Klem / Terminal
1 grau gris grauw grey
2 weiß blanche wit white
3 - - - -
4 schwarz noir zwart black
5 blau bleu
blauw
blue
U
b
7 8 9 101112
7 8 9 10 11 12
45.0
46.0
