2. Overview / Controlling parts (e.g. CRS)
GB
1. Clutch lever
Grip this lever to disengage the driving
system at the time of starting or shifting gears.
Disengage the clutch by grasping the lever.
2. Brakes
Press the right lever tightly and the
front brake applies.
To apply rear brake, use the
rear brake pedal (no. in above
overview).
1234567
8
90
(1) Rear light
(2) Rear turning lights (R/L)
(3) Muffler
(4) Seat
(5) Acceleration grip
(6) Front turning lamps (R/L)
(7) Head lamp
(8) Rear disc brake
(9) Rear brake pedal
(10) Front cushion
qwertz
poiu
(11)
(12) Rear-view mirrors
(13) Left grip switch
(14) Carburetor
(15) Air filter
(16) Rear reflector
(17) Side stand
(18) Shift pedal
(19) Side reflector
(20) Front disc brake
Cockpit
9
27
