13. Fuse / Gear oil / Tools / Disposal
GB
Fuse
The fuse is mounted on the side of the battery case cover. If the fuse
is blown, it needs to be replaced. When a light or circuit fails suddenly
check the fuse first.
Warning!
In case of replacing the fuse, pay attention that the new fuse is of the
same specification (e.g. 15A) as the original one.
Gear oil
The gear oil needs to be replaced on the first inspection and later on
according to the inspection plan. The gear oil replacement needs
to be done by an authorized service partner.
Tools
A full set of tools is offered for your daily use and is located under the
seat.
Disposal
For disposal, please contact your dealer or professional service partner.
39
14. Technical details
Size: Length x Width x Height =
Weights: Dry weight approx. 112 kg, Max. payload: 150 kg
Maximum speed: 45 km/h
Spark plug: C7HSA; Fuse: 15A
Fuel tank capacity: 10,5 +/- 0,5 litres (unleaded fuel, min. 95 octane ROZ/MOZ)
Motor: 1-cylinder, 4-stroke, air-cooled; cylinder capacity: 49,5 cm³
Max. power: 2,2 kW / 7000 rpm
Ignition type: CDI; Starting mode: Electric / kick start
Tires: 110/70-17 front; 130/70-17 rear
2120 x 840 x 1120 mm; Wheel base: 1400 mm
CRS 50
Size: Length x Width x Height =
Weights: Dry weight approx. 123 kg, Max. payload: 150 kg
Maximum speed: 100 km/h
Spark plug: C7HSA; Fuse: 10A/15A
Fuel tank capacity: 10,5 +/- 0,5 litres (unleaded fuel, min. 95 octane ROZ/MOZ)
Motor: 1-cylinder, 4-stroke, air-cooled; cylinder capacity: 124 cm³
Max. power: 6,0 kW / 7500 rpm; Ignition type: CDI; Starting mode: Electric
Tires: 110/70-17 front, 130/70-17 rear
2120 x 840 x 1120 mm; Wheel base: 1400 mm
CRS 125
