LOWEST
POSITION
MIDDLE POSITION
HIGHEST POSITION
LOWEST
POSITION
MIDDLE POSITION
HIGHEST POSITION
STEP 2
Assemble the mattress support using 4 bigger
round head bolts (5), 4 "butterfly" type nuts (7), 4
smaller lock washers (11) and a Phillips
screwdriver (not supplied). The lock washer must
be attached to the bolt after the bolt passed
through the frame and the metallic bracket of the
mattress support and before attaching the nut.
There are three positions for the mattress support
(from the highest one for a newborn to the lowest
one for a child that is maximum 35" tall - see
caution note). You must adjust the height of the
mattress support depending of your child height by
inserting all four bolts in the same position (see
FIGURE 2).
Do not completely tighten the bolts at
this step, you will be asked to do this later.
FIGURE 2
5
7
5
7
5
7
5
7
5
7
11
11
11
11
11
A D J U S T I N G T H E H E I G H T O F Y O U R M A T T R E S S S U P P O R T
To adjust the vertical position of your mattress support you must remove all four bolts & nuts (5+11+7),
loosen all four bolts (6+11), lower the frame and insert the bolts (5) back into the corresponding holes,
according to the desired height (see FIGURE 2). Then, you must attach the lock washers (9) and the nuts (7)
as described in STEP 2 and completely tighten all bolts.
Your crib is designed in such a manner that, when the mattress support is adjusted to it’s lowest
position, the mattress support frame must be placed directly over the stabilizing bars. Before tighten
the bolts, you must slightly press the mattress support frame to make sure this position is achieved.
WARNING: TO KEEP YOUR BABY SECURE AND SAFE, AND TO AVOID POTENTIAL INJURY OR
DEATH, IT'S VERY IMPORTANT TO COMPLETELY TIGHTEN ALL 8 BOLTS (5+11+7)
& (6+11) AFTER YOU HAVE ADJUSTED THE HEIGHT OF YOUR MATTRESS
SUPPORT.
NOTE: THE STYLE OF YOUR
CRIB, HEADBOARD OR OF
YOUR MATTRESS SUPPORT
MAY VARY FROM WHAT IS
P I C T U R E D I N T H E
INSTRUCTION SHEET
