Rona RFNS-001 - Parts List

14
ENGLISH FRANÇAIS
RFNS-001
PARTS LIST
Please refer to the schematic drawing on page 15
No. Description
RFNS-001-1 Screw M5 x 20
RFNS-001-2 Spring washer M5
RFNS-001-3 Bushing
RFNS-001-4 Exhaust cover
RFNS-001-5 Seal
RFNS-001-6 Screw M6 x 30
RFNS-001-7 Spring washer M6
RFNS-001-8 Cylinder cap
RFNS-001-9 Gasket
RFNS-001-10 Washer
RFNS-001-11 Valve seat
RFNS-001-12 Spring
RFNS-001-13 O-Ring 57.5 x 2.6
RFNS-001-14 O-Ring 72.4 x 3.5
RFNS-001-15 Valve
RFNS-001-16 Screw M6 x 8
RFNS-001-17 Cylinder seal
RFNS-001-18 Collar
RFNS-001-19 O-Ring 54.4 x 4
RFNS-001-20 Piston assembly
RFNS-001-21 Cylinder
RFNS-001-22 O-Ring 67 x 3
RFNS-001-23 O-Ring 60.25 x 2.5
RFNS-001-24 Restrictive plate
RFNS-001-25 O-Ring 97.5 x 3.5
RFNS-001-26 Bumper A
RFNS-001-27 Bumper B
RFNS-001-28 Body
RFNS-001-29 O-Ring 62.3 x 1.8
RFNS-001-30 Nose
RFNS-001-31 Spring washer M8
RFNS-001-32 Screw M8 x 25
RFNS-001-33 Spring
RFNS-001-34 Safety bracket A
RFNS-001-35 Screw M5 x 12
RFNS-001-36 Bushing
RFNS-001-37 Safety bracket B
RFNS-001-38 Washer
RFNS-001-39 Screw M5 x 10
RFNS-001-40 Rubber cover
RFNS-001-41 Seal
RFNS-001-42 Pin
No. Description
RFNS-001-42A Spring pin
RFNS-001-43 Safety bracket guide
RFNS-001-44 O-Ring 20.3 x 2.5
RFNS-001-45 O-Ring 20.3 x 1.5
RFNS-001-46 Valve set
RFNS-001-47 O-Ring 9.5 x 1.9
RFNS-001-48 O-Ring 10.3 x 1.9
RFNS-001-49 Trigger valve head
RFNS-001-50 O-Ring 12.8 x 1.9
RFNS-001-51 Spring
RFNS-001-52 O-Ring 5.5 x 1.5
RFNS-001-53 Trigger valve stem
RFNS-001-54 O-Ring 24.8 x 2
RFNS-001-55 Trigger valve guide
RFNS-001-56 Spring
RFNS-001-57 Trigger assembly
RFNS-001-58 Rail
RFNS-001-59 Washer M5
RFNS-001-60 Nut M4
RFNS-001-61 Washer M5
RFNS-001-62 Coil spring assembly
RFNS-001-63 Pin
RFNS-001-64 Bushing
RFNS-001-65 Screw M4 x 8
RFNS-001-66 Block
RFNS-001-67 Spring washer M4
RFNS-001-68 Screw M4 x 12
RFNS-001-69 Feeder shoe
RFNS-001-70 Screw M5 x 14
RFNS-001-71 Magazine
RFNS-001-72 Screw M4 x 16
RFNS-001-73 Support
RFNS-001-74 Nut M5
RFNS-001-75 Lock
RFNS-001-76 Torsion spring
RFNS-001-77 Bushing
RFNS-001-78 Nut M4
RFNS-001-79 Nut M6
RFNS-001-80 Soft Grip Sleeve
RFNS-001-81 O-Ring 65.4 x 2.5
RFNS-001-82 End Cap
RFNS-001-83 Air Plug
