The names if each are self-explanatory, and the following table lists each parameter with the corresponding
minimum and maximum values for each.
Controller
Min
Max
LFO RATE
0
255
LFO DELAY TIME
0
255
LFO WAVE
0
5
OSC LFO MOD
0
255
OSC ENV MOD
0
255
OSC FREQ MOD DST
0
2
PWM
0
255
PWM SOURCE
0
2
OSC1 CROSS MOD
0
255
OSC1 RANGE
0
5
OSC1 WAVE
0
5
OSC2 SYNC
0
1
OSC2 RANGE
0
255
OSC2 TUNE
0
255
OSC2 WAVE
0
5
MIX BALANCE
0
255
HPF
0
255
CUTOFF
0
255
RESONANCE
0
255
FLT LPF SLOPE
0
1
FLT ENV MOD
0
255
FLT ENV MOD SRC
0
1
FLT LFO MOD
0
255
FLT KEY FOLLOW
0
255
AMP LEVEL
0
255
AMP LFO MOD
0
3
ENV1 ATTACK
0
255
ENV1 DECAY
0
255
ENV1 SUSTAIN
0
255
ENV1 RELEASE
0
255
ENV1 POLARITY
0
1
ENV2 ATTACK
0
255
ENV2 DECAY
0
255
ENV2 SUSTAIN
0
255
ENV2 RELEASE
0
255
ENV2 KEY FOLLOW
0
3
DELAY LEVEL
0
15
DELAY TIME
0
15
DELAY FEEDBACK
0
15
PORTA SW
0
1
PORTA TIME
0
255
ASSIGN MODE
0
2
BEND RANGE
0
24
PATCH_NAME
<Name of patch>
