USER MANUAL
3
TECHNICAL SPECIFICATIONS
Model 8604
Voltage 20V
Battery Capacity 2000mAh
Paint Reservoir Volume 1200ml
Max. Viscosity 50-60din/sec
Max. Flow 600ml/min
Speed 32000RPM
Continuous Working Time 18-20 min
Battery Charging Time 60 mins
LED Voltage 16-20V
LED Power 4W
Flux 150-200LM
CCT 7200-8000K
Weight 1.1kg
Supplied in Ronix Color Box
Includes clean needle, shoulder strap,
viscosity cup, 2 battery, charger,
nozles (1/1.8/2.5mm), Spanner
