Ronix RX-AH04J User Manual

Name and Function of Each Part
Real Time Recording & Full HD Display
3. REAR PANEL - 8CH
4. REAR PANEL - 4CH
① ② ③ ④ ⑥ ⑦⑧
① VIDEO IN Camera Video Input
② AUDIO OUT Audio Output
③ HD OUTPUT HD Output Port
④ VGA Port VGA Output
⑤ ETHERNET Ethernet Connector
⑥ USB Port USB Port
⑦ MULTI Port Sensor Input, Relay Output
⑧ POWER INPUT Power input connector(Adaptor)
Name Function
⑤
① VIDEO IN Camera Video Input
② HD OUTPUT HD Output Port
③ AUDIO IN/OUT Audio Input/Output
④ VGA Port VGA Output
⑤ ETHERNET Ethernet Connector
⑥ USB Port USB Port
⑦ MULTI Port Sensor Input, Relay Output
⑧ POWER INPUT Power input connector(Adaptor)
Name Function
VIDEO IN
AOUT
SPOT OUT
AN1
AN2
VGA
NET
AUDIO IN
USB
HD OUT
1
2
3
4
5
6
7
8
ALARM
VIDEO IN
AUDIO
IN1
OUT
IN2 IN3 IN4
VGA
NET
AUDIO IN
POWER
VIDEO OUT
HD OUTPUT
3
4
1
2
ALARM
① ② ③ ④ ⑥ ⑦ ⑧
⑤

Ronix RX-AH04J Specifications

General

Brand	Ronix
Model	RX-AH04J
Category	DVR
Language	English
