RoomAndLoft Murphy - Bed Case and Wall Mounting; Setting Up the Bed Case

Wall
Setting up the Bed Case – part A
Step 1: Open Box #1, and lay out the top and bottom panels of the left and right side panels as shown, noting the distances marked between the panels
and from the bottom edge of the side panels to the wall.
3
K157B3/8” spacer blocks
K157A1/4” spacer blocks
K161B12mm wrench
K161A1/2” wrench
BUBBLE-PACK #1
CONTENTS
SHOWN ON
PAGE19
Guide Dowel
Top
right side
Bottom
right side
Top
left side
Bottom
left side
FROM BUBBLE PACK1 - HOLD THESE
PARTS ASIDE FOR LATER USE
