K117A

Safety chain from

Box2, bubble-pack 2

K113C

Bolts

K160

Allen wrench

K123

screw s

Wall

Step 2: Align the top and bottom side panels with the guide dowels, then connect by using K113C bolts through the metal plate into imbedded sleeves.

Step 3: Open Box #2 and find bubble pack 2. Install the safety chains on both size panels using K123 screws.

Step 2

Step 3
