RoomTec Murphy Bed Building Queen Vertical - Plywood Cutting and Materials; Plywood Sheet Requirements

H. Rear Rail
8' 8'
8' 8'
4' 4'
4' 4'
J. 1/4" Mattress Support
B. Side Rail
H. Header Board
F. Header Board
B. Side Rail
D. Head Rail
F. Foot Rail
H. Front Rail
G. Cabinet Verticals
E. Face Panel
Requires 1 sheet 3/4"
Requires 1 sheet 3/4"Requires 2 sheets 1/4"
Requires 2 sheets 3/4"
- 05 -
Requires: 4 sheets of 3/4" x 4' x 8' and 2 sheets of 1/4" x 4’x 8’
NOTE:Refer to page 6 for the cutting dimensions.
QUEEN SIZE DELUXE KIT VERTICAL
BED PLYWOOD CUTTING GUIDE
