ROOTS Jet E 130 - Technical Specification

4
Jet E 130 / 170
TECHNICAL SPECIFICATION
Weight - 60 kg ( for 1 Ph )
Weight - 63 kg ( for 3 Ph )
920 mm
480 mm
950 mm
High Pressure Hose
Type - 2 High Tensile Steel
Wire Braided Hose
Length - 10 m
Electrical Cable
Length - 5 m
Water Inlet Temp - 60 C°
For Single Phase
Discharge - 10 lpm
Water Pressure - 130 bar
For Three Phase
Discharge - 13 lpm
Water Pressure - 170 bar
For Single Phase
Rated voltage - 230 V
Rated current - 14 A
Frequency - 50 Hz
Total power (max) - 3 KW
Rating - S1 continuous duty
Insulation - F class
For Three Phase
Rated voltage - 415 V
Rated current - 9 A
Frequency - 50 Hz
Total power (max) - 5.5 KW
Rating - S1 continuous duty
Insulation - F class
