24
RootsScrub E4550 ES
The brush head has a swiveling feature to facilitate cleaning the
entire width of the escalator step.
Follow the below instruction to use the swivel brush head:
Swiveling the Brush Head:
In this position the drive side of the brush head is facing the left
hand side of the machine (viewed from the top). In this position
only a half of the escalator step is cleaned (A).
To clean the other half of the escalator step the brush head must
be swivelled, follow the below steps to do so:
The swivel lock is located on top of the brush head assembly, it
has a lever and a locking pin.
Escalator Step
Area cleaned
Area to
be
cleaned
(A) Brush head position - 1
Swivel lock
Press the lever downwards until the pin is released from the lock
assembly, this is noticeable as the brush head will swivel a bit.
The brush head can now be swivelled at 180° and locked. This will
enable the machine to clean the remaining half of the escalator
step with a slight overlap in the center (B).
Lever
180°
Escalator Step
(B) Brush head position - 2
Area cleaned completely
In this way it can be ensured that the escalator step is cleaned
completely in both Dry and Wet mode.
DO NOT MIX BRUSHES AND CLEAN THE ESCALATOR STEPS.
IMPORTANT
Idle side - IS
Drive side - DS
Position
IS
DS
DS
IS
MACHINE OPERATION
