RootsScrub E4550 ES
During scrubbing if the brush motor trips, reset it by pressing the
circuit breaker switch.
è Wait for 30 seconds before reset.
IMPORTANT ATTENTION
ü If the motor trips frequently, stop the cleaning operation,
disconnect the power cord and call an authorized service
center for assistance.
û Do not look for the problem by yourself.
WARNING
Float System
The machine is equipped with two floats for vacuum shut-off
function.
1. Mechanical Float - The mechanical float is located inside the
dirty water tank. It shuts off the vacuum immediately when the
float block touches the top of the suction unit.
2. Electrical Float - The electrical float is located inside the fresh
water tank. It switches off the machine as soon as the water level
drops below the set value. This function is used to prevent any
unwanted damage to the water pump.
Float block
Mechanical Float
Electrical Float
Float block
MACHINE OPERATION
