ROSCAMAT MOSQUITO - Default Chapter; Table of Contents

2
INDICE
Page nr
Chapter 0 Introduction……………………………………........……….….…….… 3
Chapter 1 Description ROSCAMAT MOSQUITO ………..….………….…….… 4
Description: Motors – Orientable headmember VH……………..…
…
5
Description: Lifter – Automatic Lubrication System ………………… 6
Chapter 2 Installation, Set up – Warnings ……………… .…………..…..……... 7
Chapter 3 Operation…….…….……………………………………………..……... 8
Chapter 4 Trouble shooting ....……………….………..…………….…..….…..… 9
Guarantee...................................................................................….
…
10
Chapter 5 Maintenance - Reparations
Clutch adjustment ……… …............................................................
Damper replacement …..…………………….………...…..…………..
11
11
Push-buttons replacement ….………………….…………………..….
.
11
Motor grip replacement ………. …………..……..……….……..….… 12
Motor or/and cooling fan substitution …………………......……..…
…
12
Oil Pump replacement ………………..……........…………....…..…
…
12
Variator’s board replacement …… …………....……………...…..…
…
13
Tool Lubrication system kit-instructions for mounting ...................... 13
Chapter 6 Replacement parts list ..…………….……………………….…..……
…
14
Chapter 7 Standard product range …..………………..……………….………… 16
Chapter 8 Annex 19
Technical data – Technical motor characteristics / Variator ..……
…
20
Technical data – Turning torque NM for threading – Machine taps 21
Working areas ROSCAMAT MOSQUITO ………....……….………
…
22
Working areas ROSCAMAT MOSQUITO VH……....…….…………
…
23
Machine section ………………………………………………….……
…
24
Machine parts description…….…….…………………………….……
…
25
General Connections Roscamat MOSQUITO …....…….….......…
…
26
Connections Roscamat MOSQUITO with Lubrication system
… 26
Notes ………………………………………………………….…………
…
27
Certificate “CE” of Conformance ……………………………………… 28
