CAUTION
EQUIPMENT DAMAGE
Failure to observe this precaution may damage equipment.
Check the GC prior to wiring to determine if it is equipped for DC power.
Procedure
1. Locate the plug-together termination block inside the electronics enclosure.
Figure 2-5: 24 Vdc power connection on the back plane
