2
© All rights reserved by Rosewill
User’s Manual
FBM-01CASE
Front I/O Pin Define
USB 2.0 CONNECTOR HD CONNECTORAC97 CONNECTOR
PinPin
MIC
AUD GND
RET~R
RET~L
MIC
MIC~BIAA
FPOUT~R
+5V
FPOUT~L
Pin
AUD GND
PRESENCE#
SENSE1_RETURN
SENSE2_RETURN
PORT1L
PORT1R
PORT2R
SENSE_SEND
PORT2L
Pin
Disassemble Chart
Front Panel
Left Side Panel
Right Side Panel
Rear 80mm Fan
Front 120mm Fan
