Rosewill PB240-RGB User Manual

2 3
RGB Advanced
Liquid CPU Cooler
PB240-RGB Quick User Guide
RGB Advanced
Liquid CPU Cooler
PB240-RGB Quick User Guide
Product Overview Installation Guide
1. Install the Fan and Radiator into PC Case
1-1 Secure fans on radiator with eight #6-32x29.5 mm screws.
1-2 Secure installed radiator in the case with eight #6-32x6 mm screws.
Backplate x 1
LGA 2011 Screw x 4
#6-32x6 Screw x 8
for Radiator
Gasket x 4 for Backplate
Liquid CPU Cooler x 1
Spring Screw x 4
Thermal Grease x 1
#6-32x29.5 Screw x 8
for Fan
Insulating Sheet x 1
Intel Clip x 1
(Pre-Installed)
AMD Clip x 1
M3.5x31 Screw x 4
for Backplate
SATA Cable x 1
3 Pin Connector
Cable x 1
RGB Hub x1
RGB Fan x 2
Remote Control x 1
Stand-Off Cylinder x 4
1
3
5
7
11
2
4
6
8
10
12
9
15
13
14
18
16
17
#6-32x6
Radiator Screws
#6-32x29.5
Fan Screws
