User Manual
USB 2.0 2-Port PCI Adapter RC100
Pin No. Definition
1 Power
2 Power
3 USB3 D-
4 USB4 D-
5 USB3 D+
6 USB4 D+
7 GND
8 GND
9 No Pin
10 NC
1. Remove your computer’s cover. (Note: If necessary, consult your computer’s manual for
help in removing the cover)
2. Locate an available PCI slot and, if necessary, remove the expansion slot bracket.
3. Insert the USB 2.0 Card gently but firmly until the card is fully seated.
4. Fasten card to the computer case using a screw.
5. Replace the computer cover.
Driver Installation
Windows®98SE Installation
Make sure your version of Windows® is 98 Second Edition by check the “Properties” of “My
Computer”.
1. Windows will detect new hardware and start the “VIA Tech 3038 PCI to USB Universal Host
