5. Pull down the lever part way to
open the bolt slightly and so that the
locking bolts are sticking out the
bottom of the receiver. You want to
be able to see the screws that are in
the left locking bolt.
6. Remove the locking bolt stop pin
screw from the left locking bolt.
7. Remove the locking bolt pin. Pull
both locking bolts from the receiver.
8. Remove the lever. Be careful not
to lose the ejector, ejector spring,
and ejector collar. These come out
the front of the breechbolt assembly
and are a loose fit
9. Remove the hammer screw. This
is also the lower tang screw. It
does double duty.
10. Hold the trigger back and
remove the lower tang by pulling it
straight back from the receiver. Be
