Rossmax TG100 - Page 2

Measurement Range 32.0ºC~42.9ºC (89.6~109.2ºF)
Display LCD 3 1/2 digits with ºC
Display resolution 0.1ºC or 0.2ºF
Accuracy ±0.1°C35.5°C~42.0°C
(±0.2°F 95.9°F~107.6°F)
±0.2°C under 35.5°C or over 42.0°C
(±0.4°F under 95.9°F or over 107.6°F)
at standard room temperature 25.0°C
(77.0°F)
Memory For storing the last measured value
Battery One 1.5 V DC. button size battery (SR41 or
LR41)
Battery Life Approx.1500 times operation or 1 year
with 1-2 measurement per day including
standby mode.
Dimension TG100 : 12.2x2.0x1.25cm
TG120 : 12.2x2.0x1.1cm
Weight TG100 : 8 grams including battery
TG120 : 9.5 grams including battery
Alar m beep sounds(beep-beep-beep10 times)
when peak temperature is reached
Environmental for
using
Temperature: 5~40ºC (41ºF~104ºF)
Humidity: ≤95%RH
Storage and trans-
portation condition
Temperature: -25~55ºC (-13ºF~131ºF)
Humidity: ≤95%RH
Accessories battery, carry case, instruction manual
Safety classication Type B Applied Part
Specications
EMC guidance and manufacturer’s declaration
This instrument is covered by a 5 year guarantee from the date of
purchase, batteries and accessories are not included. The guaran-
tee is valid only on presentation of the guarantee card completed
by the dealer conrming date of purchase or the receipt. Opening
or altering the instrument invalidates the guarantee. The guaran-
tee does not cover damage, accidents or non-compliance with the
instruction manual. Please contact rossmax service.
Warranty
IN0TG1000000000XX OBM_IB_TG100_TG120_EN_ver1303
Product Information
Date of purchase:
Store where purchased:
Price Paid (excl. Tax):
Purchase for:
www.rossmax.com
Recommended separation distance between portable and mobile RF communications equipment and the
TG100/TG120
The TG100/TG120 is intended for use in an electromagnetic environment in which radiated RF disturbances
are controlled. The customer or the user of the TG100/TG120 can help prevent electromagnetic interfer-
ence by maintaining a minimum distance between portable and mobile RF communications equipment
(transmitters) and the TG100/TG120 as recommended below, according to the maximum output power of
the communications equipment.
Rated maximum output
power of transmitter W
Separation distance according to frequency of transmitter m
150 kHz to 80 MHz
d =1,2√P
80 MHz to 800 MHz
d =1,2√P
800 MHz to 2,5 GHz
d =2,3√P
0,01 N/A 0,12 0,23
0,1 N/A 0,38 0,73
1 N/A 1.2 2.3
10 N/A 3.8 7.3
100 N/A 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation dis-
tance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter,
where P
The maximum output power rating of the transmitter in watts (W) according to the transmitter manufac-
turer.
NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reection from structures, objects and people.
Guidance and manufacturer’s declaration-electromagnetic immunity
The TG100/TG120 is intended for use in the electromagnetic environment specied below.
The customer or the user of the TG100/TG120 should assure that is used in such and environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment-guidance
Portable and mobile RF communications
equipment should be used no closer to any part of
the TG100/TG120 including cables, than the
recommended separation distance calculated from
the equation applicable to the frequency of the
transmitter.
Guidance and manufacturer’s declaration-electromagnetic emissions
The TG100/TG120 is intended for use in the electromagnetic environment specied below.
The customer or the user of the TG100/TG120 should assure that it is used in such an environment.
Emission test Compliance Electromagnetic environment-guidance
RF emissions CISPR 11 Group 1 The TG100/TG120 uses RF energy only for its internal func-
tion. Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic equip-
ment.
Guidance and manufacturer’s declaration-electromagnetic immunity
The TG100/TG120 is intended for use in the electromagnetic environment specied below.
The customer or the user of the TG100/TG120 should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment-guidance
Electro-
static discharge(ESD)
IEC61000-4-2
+ 6 kV contact
+ 8 kV air
+ 6 kV contact
+ 8 kV air
Floors should be wood, concrete or ceramic
tile. If oors are covered with synthetic mate-
rial, the relative humidity should be at least
30%
Electrical fast
transient/burst
IEC61000-4-4
+ 2kV for power
supply lines
+ 1kV for input/
output lines
Not applicable
Not applicable
Mains power quality should be that of a typi-
cal commercial or hospital environment.
Surge IEC 61000-4-5 + 1kV line(s) to
line(s)
+ 2kV line(s) to
earth
Not applicable
Not applicable
Mains power quality should be that of a typi-
cal commercial or hospital environment.
Voltage Dips, short
interruptions and
voltage variations on
power supply input
lines IEC 61000-4-11
<5% UT(>95%
dip in UT) for 0,5
cycle
40% UT(60% dip
in UT) for 5 cycles
70% UT(30% dip
in UT) for 25 cycles
<5% UT(>95%
dip in UT) for 5 s
Not applicable
Not applicable
Not applicable
Not applicable
Mains power quality should be that of a typi-
cal commercial or hospital environment. If the
user of the TG100/TG120 requires continued
operation during power mains interruptions,
it is recommended that the TG100/TG120
be powered from an uninterruptible power
supply or a battery.
Power frequency
(50/60 Hz) magnetic
eld IEC 61000-4-8
3 A/m 3 A/m The TG100/TG120 power frequency magnetic
elds should be at levels characteristic of a
typical location in a typical commercial or
hospital environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
Conducted RF
IEC 61000-4-6
Radiated RF IEC
61000-4-3
3 Vrms
150 KHz to 80 MHz
3 V/m
80MHz to 2,5 GHz
Not applicable
3 V/m
Recommended separation distance:
d = 1,2 √P
d = 1,2 √P 80MHz to 800 MHz
d = 2,3 √P 800MHz to 2,5 GHz
Where P is the maximum output power rating of
the transmitter in watts (W) according to the trans-
mitter manufacturer and d is the recommended
separation distance in metres (m).
Field strengths from fixed RF transmitters, as
determined by an electromagnetic site survey.
a. Should be less than the compliance level in each
frequency range.
b. Interference may occur in the vicinity of equip-
ment marked with the following symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reection from structures, objects and people.
a. Field strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios,amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to xed RF transmitters, an
electromagnetic site survey should be considered. If the measured eld strength in the location in which
the TG100/TG120 is used exceeds the applicable RF compliance level above, the TG100/TG120 should be
observed to verify normal operation. If abnormal performance is observed, additional measures may be
necessary, such as re-orienting or relocating the TG100/TG120.
b. Over the frequency range 150 kHz to 80 MHz, eld strengths should be les than 3 V/m.
RF emissions CISPR 11 Class B The TG100/TG120 is suitable for use in all establishments,
including domestic establishments and those directly con-
nected to the public low-voltage power supply network that
supplies buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage uctuations/icker
emissions IEC 61000-3-3
Not applicable
Rossmax International Ltd.
12F., No. 189, Kang Chien Rd., Taipei, 114,
Taiwan.
Rossmax Swiss GmbH,
Tramstrasse 16, CH-9442 Berneck, Switzerland
