DS35 Flush Mount Only
A
A
688
PIT WIDTH
688
PIT WIDTH
693
BETWEEN PITS
2200
3660 MIN. TO
NEAREST OBSTRUCTION
250
SECTION A-A
1675 TO
NEAREST
OBSTRUCTION
1675 TO
NEAREST
OBSTRUCTION
300
100800
3660 MIN. TO
NEAREST OBSTRUCTION
DIRECTION
OF APPROACH
(2) TWO 50mm PVC
PIPES ADJACENT
TO EACH OTHER
Ø76mm PVC PIPEØ50mm DRAIN HOLE
PIPES MUST BE FLUSH
WITH BOTTOM OF FLOOR
A
SECTION A-A
A
100
110
+5
-0
ROUTE CONDUIT TOWARDS THE CLOSEST DIRECTION
OF CABINET PLACEMENT. EXITING EITHER THE
SIDE OR BACK OF THE PIT IS ACCEPTABLE.
Fig. 2c
8
