DS35EX Flush Mount Only
A
A
2400
3660 MIN. TO
NEAREST OBSTRUCTION
50
SECTION A-A
00
300800
3660 MIN. TO
NEAREST OBSTRUCTION
DIRECTION
OF APPROACH
(2) TWO 50mm PVC
PIPES ADJACENT
TO EACH OTHER
Ø76mm PVC PIPEØ50mm DRAIN HOLE
PIPES MUST BE FLUSH
WITH BOTTOM OF FLOOR
A
SECTION A-A
A
100
ROUTE CONDUIT TOWARDS THE CLOSEST DIRECTION
OF CABINET PLACEMENT. EXITING EITHER THE
SIDE OR BACK OF THE PIT IS ACCEPTABLE.
1675 TO
NEAREST
OBSTRUCTION
1675 TO
NEAREST
OBSTRUCTION
688
PIT WIDTH
688
PIT WIDTH6
843(BMW) / 693
BETWEEN PITS
110
+5
-0
Fig. 2d
9
