Rotax 2005 717 RFI - Page 26

Section 02 717 ENGINE
Subsection 02 (MAGNETO SYSTEM)
16
Loctite
243
10
4.5 Nm
(40 lbfin)
9 Nm
(80 lbfin)
11
Loctite
243
8
12
14
Loctite 243
15
5.5 Nm
(49 lbfin)
13
Loctite 243
5
9
Loctite
243
7
6
145 Nm
(107 lbfft)
Loctite
648
17
3
2
1
9 Nm (80 lbfin)
Anti-seize
lubricant
9 Nm
(80 lbfin)
1
9 Nm
(80 lbfin)
1
2.6 Nm
(23 lbfin)
4
9 Nm
(80 lbfin)
5.5 Nm
(49 lbfin)
Anti-seize
lubricant
