Rotel RT-09 - Connections and Setup; Hook-up Illustration; Important Connection Notes

5
English
Figure 2: Hook-up Illustration
DIGITAL AUDIO DEVICE
AMPLIFIER
WI-FI DONGLE
POWER
R T - 0 9
PUSH SELECT
QUEUE
P L A Y
SKIP --
BACK R E P L Y
PA US ESTOP
SKIP +
1 2 3
4 5 6
7 8 9
MEMORY0
DAB i-RADIOFMAUX USBNETWORK
Important Notes
When making connections be sure to:
4
Turn off all the components in the system
before hooking up any components,
including loudspeakers.
4
Turn off all components in the
system before changing any of the
connections to the system.
It is also recommended that you:
4
Turn the volume control of the amplifier
all the way down before the amplifier
is turned on or off.
