Rotex HPSU compact 304 - Set Temp Day Rotary Switch Setting; Set Temp Night Rotary Switch Setting; DHW Set Temp Rotary Switch Setting

6 x Parameter settings
BA ROTEX HPSU compact 4 - 09/2013
33
6.5 Rotary switch setting: Set Temp Day
Parameter Designation Access Setting range
Min / Max
Factory
setting
Increment
BE HF
T-Room 1 Setpoint The set value of the room temperature in °C that applies to the first switching cycle of the timer
p
rogrammes [Automatic 1] and [Automatic 2].
E E 5 - 40°C 20 °C 0.5 °C
T-Room 2 Setpoint Set value of the room temperature in °C that applies to the second switching cycle of the timer
p
rogrammes [Automatic 1] and [Automatic 2].
E E 5 - 40°C 20 °C 0.5 °C
T-Room 3 Setpoint Set value of the room temperature in °C that appl
ies to the third switching cycle of the timer
programmes [Automatic 1] and [Automatic 2].
E E 5 - 40°C 20 °C 0.5 °C
Tab. 6-7 Parameter in rotary switch setting "Set Temp Day"
6.6 Rotary switch setting: Set Temp Night
Parameter Designation Access Setting range
Min / Max
Factory
setting
Increment
BE HF
T-Reduced Set value of the setback room temperature in °C which applies to the timer programmes 
[Automatic 1] and [Automatic 2].
E E 5 - 40°C 15 °C 0.5 °C
T-Absence Set value of the setback room temperature in °C which applies to the timer programmes 
[Away] + [Vacation].
E E 5 - 40°C 15 °C 0.5 °C
Tab. 6-8 Parameter in rotary switch setting "Set Temp Night"
6.7 Rotary switch setting: DHW Set Temp
Parameter Designation Access Setting range
Min / Max
Factory
setting
Increment
BE HF
T-DHW Setpoint 1 Set value of the hot water temperature in °C that applies to the first switching cycle of the timer
p
rogrammes [Automatic 1] and [Automatic 2].
E E 10 - 70°C 48 °C 1 °C
T-DHW Setpoint 2 Set value of the hot water temperature in °C that applies to the second switching cycle of the
t
imer programmes [Automatic 1] and [Automatic 2].
E E 10 - 70°C 48 °C 1 °C
T-DHW Setpoint 3 Set value of the hot water temperature in °C that applies to the third switching cycle of the timer
p
rogrammes [Automatic 1] and [Automatic 2].
E E 10 - 70°C 48 °C 1 °C
Tab. 6-9 Parameter in rotary switch setting "DHW Set Temp"
