Roto 125 FS - Page 13

Tightening torque
Spark plug..............................................20 Nm
Rocker arm cover ................................ 2,2 Nm
Rocker arm ..............................................2 Nm
Cylinder head ..........................................5 Nm
ROTOmotor Ltd., Czech Republic - Europe
ROTO 125 FS
ROTOmotor Ltd., Czech Republic - Europe
Operating instructions
ROTOmotor manufacturer of top four-stroke engines
Page:13
Adjusting the first cylinder head
Adjusting the second cylinder head
Valves adjustment
Suction valve .................................. 0,1 mm
Exhaust Valve ................................ 0,2 mm
4
2
E S
S E
1
3
1
2
3
4
S
E
If you have no experience with this type of engine adjustment:
1. Pack the engine and send it for adjustment to your specialist garage, where
the engine will be adjusted for you.
2. Ask the manufacturer by email at techinfo@rotomotor.cz
