RotoZip DM10 - Functional Description and Specifications; Coupler Compatibility

DM10 Dust Collection At-
tachment is intended to
be used with RotoZip tool models RZ2000,
RZ1500, SS560VSC, SS565VSC, SS355.
Using tools not compatible with this attach-
ment may cause personal injury or property
damage.
Coupler Compatibility
* RZ Connect Coupler and Thumbscrew to
be used on RZ Connect compatible tools
RZ2000, RZ1500, SS560vsc.
** RotoSaw Coupler to be used on RotoZip
tool model SS355
Fig. 1
Functional Description and Specifications
Disconnect the plug from the power source before making any assem-
bly, adjustments or changing accessories. Such preventive safety mea-
sures reduce the risk of starting the tool accidentally.
Model DM10
FAN
HOUSING
ROTOSAW
COUPLER**
RZ CONNECT
COUPLER*
DUST CANISTER
COLLET FAN
RZ CONNECT
THUMBSCREW*
COLLET
WRENCH
