Engine Compartment
140
UNDERBONNET LOCATIONS
1.8 petrol engines
While working in the
engine compartment,
always observe the safety
precautions listed under ‘Safety
in the garage’ on a previous
page.
1. Brake reservoir (black cap)
2. Power steering reservoir (black cap)
3. Cooling system reservoir
4. Engine oil filler (yellow cap)
5. Engine oil dipstick (yellow)
6. Washer reservoir (blue cap)
H2780
1
4
5
6
2
3
