Fuses
161
ENGINE COMPARTMENT FUSE BOX
Fuse number Rating (AMPS) Circuit protected
23 10A Airbag SRS
24 5A ABS
25 20A Front wiper system, headlight wash
26 20A Engine management system (EMS)
27 10A Air conditioning compressor
28 30A Ignition coils (EMS)
29 10A Key inhibit solenoid
30 30A Heated front screen
31 30A Air-conditioning
32 30A Heated front screen
33 5A Diagnostics
34 30A Heater blower
35 10A Air conditioning, air suspension
36 30A Air-conditioning
37 30A Engine management system (EMS)
38 30A ABS
39 20A Fuel pump
40 40A Starter motor, air suspension
41 20A Horn
42 10A Heating & ventilation
43 30A Heater blower
44 30A Engine management system (EMS)
Spare fuses 5A, 10A, 20A, 30A, 40A
Maxi 1 60A *
Maxi 2 50A Engine management system (EMS)
Maxi 3 40A ABS pump
Maxi 4 60A *
Maxi 5 60A *
* Failure of one of these fuses will result in the
message centre displaying various messages
simultaneously. Do not attempt to replace the
fuse; contact your Land Rover dealer.
