Rowe BC100 - Operational Overview; Dip Switch Settings

OPERATIONAL OVERVIEW
The hopper LED lights while the hopper is running
The meter clicks once per dollar value at the end of the vend cycle
Headers P1 and P2 are not used in this application; reserved for SBC2/SBC4.
Dip Switch Settings
AE2400 $1-$5 AE2600 $1-$20 VN2500 $1-$5
1. ON 1. ON 1.
ON
2. ON 2. ON 2.
ON
3. OFF 3. ON 3.
OFF
4. ON 4. ON 4.
ON
5. ON 5. ON 5.
ON
6. ON 6. OFF 6.
ON
7. OFF 7. OFF 7.
ON
8. ON 8. ON 8.
OFF
Revision 072502
