To dene a User Color please press ENTER to access to main menu (level 1).
While using the UP / DOWN arrows, please select the menu item “Stand Alone” and conrm
by pressing ENTER.
Select the item menu “User Color” by using the up/down controls and press ENTER.
Using UP and DOWN select your desired preset number (Color 1 -5) and conrm with ENTER.
Use UP and DOWN controls to select your desired color, conrm by ENTER and adjust the value by up and down
controls between 000-255 and conrm all entries with ENTER.
With dimmer you can adjust the allover brightness of your User Color. Shutter allows several strobe effects. Once your
color mix is ready, jump back by ESC. Your individual color is stored under the selected color preset now.
*
Note: All ve User Colors are also available by DMX at Color Macro channel.
For detailed information please see Color Macro Chart at the end of this manual.
Using UP/DOWN arrows at homescreen the Color Macros can be changed according to the list.
Shutter: Please see detailed explanation for strobe effects inside DMX chart at the end of this manual.
Color Settings*
Here at “Color Settings” you can chose your preferred working color mode for all Stand Alone modes. Either Color
Calibration or RAW. Chose Color Calibration if the xture should work accroding to the settings at Color Calibration,
either Full Calibration or CCT Calibration, RAW works according to the settings at RAW Balance, either RAW or User
Calibrated.
5.4.5 Settings
Menu
Level 1
DMX Mode
Stand Alone
Settings
System Info
Stand Alone Mode
Level 2
Stop Stand Alone
Auto FX
Color Macro
Quick Color
Tunable White
User Color
Color Settings
Color Settings
Level 3
Color Calibration
RAW
Menu
Level 1
DMX Mode
Stand Alone
Settings
System Info
