Protected against a solid object
exceeding 50mm, for example,
a hand.
Protected against vertically falling
water drops. Limited inltration is
permitted.
Protected against a solid object
exceeding 12.5mm, for example,
a nger.
Protected against vertically falling
water drops when the enclosure is
tilted up to 15 degrees from the ver-
tical. Limited inltration is permitted.
Protected against a solid object
exceeding 2.5mm, for example,
a screwdriver.
Protected against the impact of
being immersed in water under pres-
sure for prolonged periods of tim
e.
Protected against the impact of
being immersed in water between
15cm and 1m for 30 minute s.
Protected against strong water jets.
Limited inltration is permitted.
Dustproof. No inltration of dust.
Protected against water jets. Limited
inltration is permitted.
Dust protected. Limited ingress of
dust allowed. Does not affect the
operation of the device.
Protected against a solid object
exceeding 1mm, for example, a wire.
Protected against splashes of water
from all directions. Limited inltration
is permitted.
Protected against water spray up to
60 degrees from the vertical. Limited
inltration is permitted.
Ingress Protection
7.2 IP Rating
ROXX products conform to ofcially classied IP standard levels. CLUSTER S2 is rated to IP65 when using the covers
for the housing parts. IP stands for Ingress Protection and IP65, according to classied standard, means shielded
against dust and high-pressure jets of water from any side.
