33
User
Manual
7.3 Technical Data
User
Manual
Photometrics
LED expected lifetime 50.000 hours
Lightsource 612x CW LED´s (7000K), 680x RGB LED´s
Type of optical system native, elliptical lens
LED PWM Frequency selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz
Beam angles @ Full (50%) 66°
Maximum Field angles @ Full (10%) 108°
Color temperature range 2000-10.000K
CRI/Ra @ Full 88
Efcancy @ Full (max) 48,07 lm/W
Luminous ux @ Full 57.750 lm (1200W)
Luminous ux @ Full (illumination mode) 14.807lm (305W)
Luminous ux @ Center Strobe (Boost Mode) 70.661lm (1135W)
Luminous ux @ 4x Single Strobes (Boost Mode) 35.582lm (982W)
Luminous ux @ 2x RGP Panels (Boost Mode) 22.685lm (853W)
Luminous ux @ Center Strobe (Illumination Mode) 20.260lm (300W)
Luminous ux @ 4x Single Strobes (Illumination Mode) 14.480lm (300W)
Luminous ux @ 2x RGP Panels (Illumination Mode) 7.920 lm ( 3 0 0W )
illuminance Lux @ 3m / 9,84ft (@ Full) 4460lx / 414fcd
illuminance Lux @ 3m / 9,84ft (@ Center Strobe ) 3500lx / 325fcd
illuminance Lux @ 3m / 9,84ft (@ 4x Single Strobes) 2560lx / 238fcd
illuminance Lux @ 3m / 9,84ft
(@ Center Strobe + 4x Single Strobes)
4045lx / 376fcd
illuminance Lux @ 3m / 9,84ft (@ 2x RGB Panels) 1075lx / 100fcd
Thermal Characteristics
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 95%
Temperature range, Operating -40°C to 45°C
Temperature range, Start-Up -20° to 45°C
Temperature range, Storage -40°C to 80°C
Thermal Protection Automatic overtemperature protection
Electrical Data
AC Power, max 90 – 285V 50/60Hz
AC Power, nominal 100 – 240V 50/60Hz
Electrical protection Overload protection with automatic recover
Max power consumption 1250W
Constant power consumption (Illumination Mode) 320W
Power Max. Out 6,24A @ 230V / 6,14A @ 120V
Power Linking @ Max Power Consumption (Boost Mode)
1 unit @ 230V / 0 unit @ 120V
Power Linking @ Constant Power Consumption
(Illumination Mode)
7 units @ 230V / 3 units @ 120V
Power Factor 0.998 PF (230V) / 0.997 PF (120V)
Power Supply Unit Inbuilt auto-ranging electronic switch-mode
