7.3 Technical Data
User
Manual
Operator & Controller
DMX channels
Simple Mode 15CH, Easy Mode 39CH, Standard Mode 72CH (default mode), Pure
Mode 112CH Single Pixel 8 Bit with Strobefunction, Pure Mode 209CH Single Pixel
16 Bit with Strobefunction, Full Access Mode 177CH 8 Bit single Pixel with Pattern,
Full Access Extended Mode 274CH 16 Bit with Pattern
DMX modes 7
Protocol
USITT DMX512A
RDM ANSI E1.20
Art-Net
sACN
Setting and addressing
OLED graphical display / 4 controls
RDM ANSI E1.20
Standalone mode Auto Program, Color Macro, Quick Color, Tunable White, User Color
Wireless DMX n.a.
Indicator OLED graphical display
Controls 4 touch sensitive, backlighted controls
Strobe 0-30Hz
DMX I/O IP65 XLR 5-pin male/female
Ethernet I/O IP65 RJ45 Ethernet male/female
Power In TRUE1 compatible input & link-thru sockets
USB Firmware Update IP65 USB socket
Dimensions & Weight IP65 USB socket
IP class IP65
IK class IK08
Body material Aluminum, Nylon
Lens material Tempered glass front
Net dimensions without Yoke (w x h x d) 400 x 200 x 191mm
Net dimensions inches 15,75 x 7,87 x 7,52 inches
Net weight (incl. Yoke) 12,6 kg (27,78lbs)
Tilt 360°
Tilt Locking System Locking system with toothing and angle indicator
Included / Optional
Included items Yoke 4.1, 2m Power Cable, Puk
Optional Accessories Yoke 2.2, Yoke 4.3, Yoke Floor Extension, Rigging Bracket, Omega Bracket ST
Color options Black – RAL 9004 (Standard) / Custom color – any RAL (on request)
Installation
Mounting point by Yoke (included)
3x 13mm / 1/2" holes, 1x centric TV Spigot attachement, 3x integrated Camlocks
for Omega Brackets
Mounting point on xture 1/4 turn Omega Bracket on top and rear side
Mounting point with otional Rigging Bracket 2x 13mm / 1/2" holes for Clamp xation
Orientation Any
Rigging possibilities Hanging or ceiling / pendant mount
Safety features 2x rear mount for safety wire
Minimum distance from ammable materials 0,3 meters (11,8 inch)
