List of parts
No
Part name
No
Part name
1
Condensed water drain
12
Back panel
2
Drip tray cover
13
Center panel
3
Drip tray
14
Proximity switch assembly
4
Dispensing door front panel
15
Gear motor
5
Front panel
16
Electrical box
6
Footers
17
Evaporator assembly
7
Compressor
18
Ice mass inlet pipe
12
Filter
19
Tank cover
11
Condenser
20
Operation panel
10
Base plate
21
Dispensing door assembly
11
Rear support frame
