Royal Klima 6 User Manual

KLIMA 6 cod. 004772220 - 05/2013 57/72
CN9 CN1CN5 CN4CN8 CN7CN13
ELEKTRISCHES MONTAGESCHEMA
.........MASSE
.........DRUCKWAECHTER
.........GLUTFEST (4) (5)
.........SPENDER (2) (7)
.........RAUMTEMPERATURREGLER (3) (6)
.........STEUERPANEEL
.........RAUCHSONDE (9) Rot (+) - (10) Blau (-)
.........RAUMSONDE (5) (6)
.........
PELLETSONDE (3) (4)
.........ABGASVENTILATOR (10) (11)
.........RAUMLUFTGEBLAESE (8) (9)
.........VERSORGUNG 230 V 50 Hz (12) (13)
.........HALL FUEHLER (1) (2) (3)
.........SERIENAUSGANG

Royal Klima 6 Specifications

General

Brand	Royal
Model	Klima 6
Category	Stove
Language	English
