Documenting Multifunction Calibrator / EN
06/04/2018 Version No. 1
Table of Contents
FEATURES: ....................................................................................................................... 1
APPLICATIONS: ............................................................................................................... 2
I. PANEL DESCRIPTION ................................................................................................. 3
II. OPERATION .................................................................................................................. 4
1. VOLTAGE SOURCE ....................................................................................................... 4
1a. 0V ~ 15V .............................................................................................................. 4
1b. How to set up .................................................................................................... 5
1c. Details for set up............................................................................................... 6
2. CURRENT SOURCE ...................................................................................................... 7
2a-1. 4 ~ 20mA .......................................................................................................... 7
2a-2.
Output (4~20mA) and Facilitating use with HART
TM
Communicator
....... 8
2a-3.
Simulating a Transmitter
................................................................................ 9
2a-4
Simulating Electronic Load (Max. 30V, 24mA)
.......................................... 10
2a-5
LED Brightness Testing (0~24mA)
........................................................... 11
2b. How to set up .................................................................................................. 12
2c. Details for set up............................................................................................. 13
2d. MAPPING Function ........................................................................................ 14
3. TEMPERATURE SOURCE (THERMOCOUPLES, ℃&℉) .............................. 15
3a. TC Simulating Thermocouple Signals ...................................................... 15
3b. How to set up .................................................................................................. 16
3c. Details for set up............................................................................................. 16
4. FREQUENCY (HZ) OUTPUT ........................................................................................ 17
4a. 0.1Vpp ~ 20Vpp , 0.3Hz ~ 20KHz , offset: -5V ~ +5V ............................... 17
4b. How to set up .................................................................................................. 18
4c. Details for fine-tuning items ........................................................................ 19
