Documenting Multifunction Calibrator / EN
06/04/2018 Version No. 1 1
Features:
1. Unique mapping function let you calibrate temperature (300 °C) or voltage
(220V) directly (instead of 4 to 20mA indirectly).
2. A multifunction calibrator and an arbitrary function generator.
3. Simulate a current transmitter.
4. 4~20mA (open voltage 24V) direct source mode.
5. Make a measurement and output loop power 24V (LOOP+) simultaneously.
6. User selectable HART
TM
resistor to facilitate use with HART
TM
communication devices.
7. Electronic load (max. 30V, 24mA).
8. Source: mA (4 to 20mA), V (0 to 15V, 0 to 70mV), Hz, sine wave, square
wave, triangular wave, truncated sine wave, user programmable waveform
and temperature for 11 types of thermocouples.
9. Measure: Current (mA), Voltage (V, mV) and temperature in ℃ or ℉.
10. Programmable cold junction compensation allows users to fine tune
temperature output and measurement.
11. Programmable 0% and 100% value for easy 25% step function.
12. Output error warning when output is shorted or open.
13. Short circuit protection for voltage output.
14. Clear and easy user interface (Numerical key pad, sliding switch and dot
matrix LCM with backlight).
15. Voltage, frequency, PWM duty-cycle (square wave and triangular wave), and
offset are programmable in the Hz function.
16. Frequency range (0.3Hz to 20KHz) covers application of audio band
(speaker, MP3, MD etc.)
17. DTMF (Dual Tone Multi-Frequency) can perform professional testing for
telephone line and audio product (MP3 or MD).
18. Auto-step and auto-ramp functions can quickly perform linear test.
19. PC can program calibrator through USB port.
20. Perform data logging with programmable sampling time (0-255 seconds) and
memory of 4000 records.
21. Rechargeable Lithium battery (1600mAH) with built-in charging circuit.
