Series 5 10G Network Daughter Card Installation Guide
The following diagram shows the parts used when replacing the 10G Network Daughter card.
Key Description Key Description
1 Captive screw socket (2) 4 Touch point (2)
2 Connector on the system board 5 Network daughter card
3 Captive screw (2) 6 Back panel slot for Ethernet connectors
