Series 5 10G Network Daughter Card Installation Guide

Key Description Key Description

7 Riser card 3 15 Hard drive

8 Network daughter card

Parts for Installing or Replacing the 10G Network Daughter Card

The following figureshows how to remove the PERC H830 expansion card to gain access to the

Network Daughter card.

Key Description

1 Connector

2 Expansion-card latch

3 PERC H830 expansion card

4 Back panel slot

7 Series 5 10G Network Daughter Card Installation
