RuarkAudio R3 - Page 8

EN
40
39 41
42
46
45
44
43
343332 35 36 3837
Overview
32. Remote receiver
33. Ambient light sensor
34. CD eject button
35. OLED display
36. Controls
37. CD loading slot
38. 75mm Ruark NS+ drivers
39. USB C (5V 1A)
40. Optical input
41. Ethernet
42. DAB-FM antenna
43. DC power input (14V 2.85A)
44. Line in (phono)
45. Line out (phono)
46. Headphone out (3.5mm jack)
