Ruijie Reyee RG-RAP6262 Series

Hardware Installation and Reference Guide 1 Product Overview
4
Solid on
The port is up and no data is transmitted.
Off
The port is not connected.
LAN 2(Green)
Blinking
The port is up and data is transmitted.
Solid on
The port is up and no data is transmitted.
Off
The port is not connected.
Table 1-3 Reset Button
Button
Function
Operation
Reset
Reboot
Press the button for less than 2 seconds, and the device
will be rebooted.
Restore Factory Settings
Press the button for over 5 seconds, and the device will
restore the factory settings.
1.2 Appearance
The RG-RAP6262(G) provides a Wi-Fi indicator, a SYS indicator, and two LAN port indicators.
Figure 1-1 Appearance
1.3 Ports
Figure 1-2 Ports
