US I american
PRECISION TOOLS
Drilling unit RS130e
Drilling mechanism RS130e
Pos. Description Article no. Quantity
1 Machined body + brass plate 711 2 200 1
2 Spring plunger 711 4 007 1
3 Pinion shaft 711 3 217 1
4 Star grip with threaded rod 711 4 003 1
5 Bearing bowl 711 3 212 2
6 Safety ring 611 9 306 2
7 Balance plate 611 9 813 1
8 Threaded pin M5x12 611 9 004 4
9 Cylinder head screw M5 x 10 611 9 024 1
10 Toothed disc 5.3 mm 611 9 405 3
11 Hexagon socket screw M3x8 611 9 045 10
12 Cable gland 611 9 854 1
13 Cool bottle 711 4 013 1
14 Lid for cool bottle 108 1 01-4 1
15 Connection cooling 711 4 010 1
16 Switch magnet 611 4 402 1
17 Adapter for handle 711 3 216 1
18 Hand lever compl. 711 4 016 3
19 Set screw with flat point M8x8 611 9 043 3
20 Guide rail 611 3 228 2
21 Cylinder head screw M5x20 611 9 002 6
22 Cylinder head screw M3x20 711 4 001 2
23 Cylinder head screw M8x30 611 9 034 1
24 Cylinder head screw M8x20 611 9 063 1
25 Magnet + fine adjustment compl. 711 1 001 1
26 Carriage 711 3 218 1
27 Toothed rack 611 3 222 1
28 Cylinder head screw M6x12 611 9 026 3
29 Cylinder head screw M8x16 611 9 020 6
Pos. Description Article no. Quantity
30 Motor housing 711 3 002 1
31 Pole ring, cpl. 711 3 001 1
B3 Pocket brush holder, cpl. 711 3 004 2
32 Corrugated spring washer B4 611 1533 4
33 Cold-forming tapping screw ZM4x12 611 1 530 4
34 Carbon brush, cpl. 711 3 005 2
35 Nut M4 711 3 039 1
36 Flexicon clip 711 3 013 1
37 Screw M4x10 711 3 010 1
38 PCB - 115 V 611 3 560 1
39 Tapping screw HC 4.2 x 9.5 711 3 009 2
40 Screw 3.9x50 611 3 504 4
41 Cap 711 3 006 1
42 Grease chamber bulkhead 711 3 034 1
43 O-ring 106x2 711 3 011 1
44 Gear bearing plate 711 3 012 1
45 Grooved dowel pin 5x12 711 3 035 1
46 Air guide ring, cpl. 711 3 003 1
47 Circlip 11/1 611 2 519 1
48 Grooved ball bearing 6001 2RS 711 2 017 1
49 Circlip 28/1.2 611 1 524 1
B1 Armature, cpl. - 115 V 611 4 534 1
50 Grooved ball bearing 6000 2Z 711 3 007 1
51 Ring magnet 611 3 534 1
52 Disc made of press board 611 3 533 1
53 Bearing cap 711 3 008 1
54 Carbon support strand 711 2 505 2
